Tilt-a-Whirl Breakout - RPI-1031

Tilt-a-Whirl Breakout - RPI-1031

Description: The RPI-1031 tilt sensor is capable of sensing a change in orientation in four different directions: forward, back, left or right. This breakout board makes it easier to incorporate the RPI-1031 in your next project by breaking the necessary pins out to standard 0.1" spaced headers. This board will work at either 3.3 or 5V.

Documents:

• Schematic
• Eagle Files
• Datasheet (RPI-1031)
• Product Page(RPI-1031)
• Hookup Guide
• bildr Tutorial
• Product Video
• GitHub
