This is a basic, 4-digit 7-segment display - red in color. It has a common anode. The display features one decimal point per digit, and individually controllable apostrophe and colon points. The...

This is a basic, 4-digit 7-segment display - red in color. It has a common anode. The display features one decimal point per digit, and individually controllable apostrophe and colon points. The LEDs have a forward voltage of 2.1VDC and a max forward current of 20mA. The hardware interface is sixteen (two rows of eight) through-hole pins. We carry this same display in yellow, green, and blue. Features: Overall Display: 40.18 x 12.8 mm (1.58 x 0.50") Digit Height: 10mm (0.39") Documents:...

This is a 3-terminal microswitch, with a small push-button. This switch has a great 'clicky' sound to it, and a nice tactile feel. Features: Max 4A 125/240VAC 2 mounting holes Long mechanical...

This is a 3-terminal microswitch, with a small push-button. This switch has a great 'clicky' sound to it, and a nice tactile feel. Features: Max 4A 125/240VAC 2 mounting holes Long mechanical operating life Contact resistance: less than 0.2Ω Insulation resistance: 500Ω minimum @500VDC Rated to 10000 clicks 0.63x1.1x0.42" Weight: 5g

Here we have some right-angle headers with 40x3 pins. They are break away and will take a bit of effort to break this beast where you need it to break. That being said, if you need a big header like...

Here we have some right-angle headers with 40x3 pins. They are break away and will take a bit of effort to break this beast where you need it to break. That being said, if you need a big header like this, it's easy enough to break it where you need. The pins are spaced at 0.1" and there are 3 rows of 40 pins. These work well in the UAV boards listed below.

This is a simple slide switch for the LilyPad. Use it as a simple ON/OFF switch, or to control LEDs, buzzers, sensors, etc. The swtiches on each board are rated for 4 volts at 300mA, but will work...

This is a simple slide switch for the LilyPad. Use it as a simple ON/OFF switch, or to control LEDs, buzzers, sensors, etc. The swtiches on each board are rated for 4 volts at 300mA, but will work at 5 volts with a reduction in current. LilyPad is a wearable e-textile technology developed by Leah Buechley and cooperatively designed by Leah and SparkFun. Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing. Various input, output, power, and...

Apply 5V and be shaken by this small, but powerful vibration motor. Works great as an physical indicator without notifying anyone but the wearer. This version uses a surface mount motor which is...

Apply 5V and be shaken by this small, but powerful vibration motor. Works great as an physical indicator without notifying anyone but the wearer. This version uses a surface mount motor which is less likely to be damaged during use. LilyPad is a wearable technology developed by Leah Buechley and cooperatively designed by Leah and SparkFun. Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing. Various input, output, power, and sensor boards...

The LilyPad MP3 Player is your all-in-one audio solution, containing an Arduino-compatible microcontroller, MP3 (and many other formats) audio decoder chip, micro-SD card socket, and a stereo audio...

The LilyPad MP3 Player is your all-in-one audio solution, containing an Arduino-compatible microcontroller, MP3 (and many other formats) audio decoder chip, micro-SD card socket, and a stereo audio amplifier. Part of the Lilypad E-textiles line, this board can be used to give your fabric creations the gift of music, or any other sounds you can put on a micro-SD card. It can be powered by a 3.7V Lipo battery (charging circuit built-in!), or an external 3.5-6V source. Off the shelf, it will play...

Arduino is an open-source physical computing platform based on a simple i/o board and a development environment that implements the Processing/Wiring language. Arduino can be used to develop...

Arduino is an open-source physical computing platform based on a simple i/o board and a development environment that implements the Processing/Wiring language. Arduino can be used to develop stand-alone interactive objects or can be connected to software on your computer (e.g. Flash, Processing, MaxMSP). The open-source IDE can be downloaded for free (currently for Mac OS X, Windows, and Linux). The Arduino Mega is a microcontroller board based on the ATmega2560. It has 54 digital input/output...

This board allows you to interface with your car's OBD-II bus. It provides you a serial interface using the ELM327 command set and supports all major OBD-II standards such as CAN and JBUS. The board...

This board allows you to interface with your car's OBD-II bus. It provides you a serial interface using the ELM327 command set and supports all major OBD-II standards such as CAN and JBUS. The board also provides a footprint which mates directly to our FTDI Basic. The DB9 connector mates with our DB9 to OBD-II cable listed below. On-Board Diagnostics, Second Generation (OBD-II) is a set of standards for implementing a computer based system to control emissions from vehicles. It was first...

This is a USB to TTL Serial Cable which allows for a simple way to connect TTL interface devices to USB. The I/O pins of this cable are configured to operate at 3.3V specifically with a Raspberry Pi...

This is a USB to TTL Serial Cable which allows for a simple way to connect TTL interface devices to USB. The I/O pins of this cable are configured to operate at 3.3V specifically with a Raspberry Pi with each serial pin broken apart. Thanks to its separated pins, this cable is a perfect candidate for powering, connecting, and accessing the login and debug console on the Raspberry Pi. The FTDI cable is designed around an FT232, which is housed in a USB-A connector. The other side of the cable...

This 2x20 flat ribbon-cable fits the GPIO headers on the Raspberry Pi 3, 2, and B+ so you can easily connect to the low-level peripherals and get hacking! This cable has 0.1"-spaced connectors and...

This 2x20 flat ribbon-cable fits the GPIO headers on the Raspberry Pi 3, 2, and B+ so you can easily connect to the low-level peripherals and get hacking! This cable has 0.1"-spaced connectors and is keyed for polarity. Features: 6" long Documents: Datasheet Product Video Videos ...

A Quad-band antenna for embedded cellular devices. This antenna will allow you to connect your cellular module to the outside world. Operates on four frequencies. Comes with a 3M adhesive backing...

A Quad-band antenna for embedded cellular devices. This antenna will allow you to connect your cellular module to the outside world. Operates on four frequencies. Comes with a 3M adhesive backing for mounting. Standard male SMA terminated. Key Specifications: Quad-band: 850/900/1800/1900MHz and 2.4GHz For GSM/GPRS, CDMA/1X, TDMA/AMPs, CDPD, 2 Way pager Re-Flex Cable with RG174A/U - 3m long Connector: SMA Electrical Properties: Frequency range: 824 ~ 960 MHz // 1710 ~ 1990 MHz Impedance: 50 Ohm...

This is a fantastic find for SFE. A small, high-quality, quad-band, standard SMA terminated, cellular antenna. Specifications: GSM/850E : 824 to 894MHz GSM : 880 to 960MHz DCS : 1710 to 1880MHz PCS...

This is a fantastic find for SFE. A small, high-quality, quad-band, standard SMA terminated, cellular antenna. Specifications: GSM/850E : 824 to 894MHz GSM : 880 to 960MHz DCS : 1710 to 1880MHz PCS : 1850 to 1990MHz Documents: GSM Antenna 850-1900MHz

This high gain, 7.75" antenna is perfect for AVL applications where cellular reception is a must. Connector is regular SMA so don't confuse it with 2.4GHz antennas. Specifications: GSM/850E : 824 to...

This high gain, 7.75" antenna is perfect for AVL applications where cellular reception is a must. Connector is regular SMA so don't confuse it with 2.4GHz antennas. Specifications: GSM/850E : 824 to 894MHz GSM : 880 to 960MHz DCS : 1710 to 1880MHz PCS : 1850 to 1990MHz Documents: Datasheet

These are very small surface mount quartz crystals used where size is a concern. Ideal for use with the nRF2401 ICs. 2****0ppm * 18pF load capacitance Features: Small 5x3.2mm footprint Operating...

These are very small surface mount quartz crystals used where size is a concern. Ideal for use with the nRF2401 ICs. 2****0ppm * 18pF load capacitance Features: Small 5x3.2mm footprint Operating temperature: -20°C ~ +70°C Frequency Tolerance: +/- Documents: Datasheet ...

Electrolytic decoupling capacitors 100uF/25V. These capacitors are great transient/surge suppressors. Attach one between the power and ground of your project to ensure smooth power delivery. High...

Electrolytic decoupling capacitors 100uF/25V. These capacitors are great transient/surge suppressors. Attach one between the power and ground of your project to ensure smooth power delivery. High quality radial electrolytic capacitors. Check out our Unregulated Power Supply Tutorial

We use these little buttons on everything! These Miniature Single Pole Single Throw switches have a good click to them and are breadboard friendly. Perfect as a tactile reset switch. These momentary...

We use these little buttons on everything! These Miniature Single Pole Single Throw switches have a good click to them and are breadboard friendly. Perfect as a tactile reset switch. These momentary buttons are rated up to 50mA. Documents: Dimensional Drawing (NEEDS UPDATE! COMING SOON!)

These are high quality Single Pole - Double Throw (SPDT) sealed relays. Use them to switch high voltage, and/or high current devices. This relay's coil is rated up to 12V, with a minimum switching...

These are high quality Single Pole - Double Throw (SPDT) sealed relays. Use them to switch high voltage, and/or high current devices. This relay's coil is rated up to 12V, with a minimum switching voltage of 5V. The contacts are rated up to 5A (@250VAC, 30VDC). Note: In the Datasheet below there is a pin layout listed as "Bottom View." Be aware, this pin layout is actually the top-down view NOT bottom-up. Features: 5V DC SPDT Relay Rated up to 5A Fully Sealed Documents: Datasheet ...

Simple SPDT slide switch. Rated at 30V/200mA. The pins have .1" spacing - fits great into a breadboard! Use it as a power switch or general control switch. Documents: Dimensional Drawing ...

Simple SPDT slide switch. Rated at 30V/200mA. The pins have .1" spacing - fits great into a breadboard! Use it as a power switch or general control switch. Documents: Dimensional Drawing

Ever hear of a thing called RGB? Red, Green, Blue? How about an RGB LED? These 5mm units have four pins - Cathode is the longest pin. One for each color and a common cathode. Use this one LED for...

Ever hear of a thing called RGB? Red, Green, Blue? How about an RGB LED? These 5mm units have four pins - Cathode is the longest pin. One for each color and a common cathode. Use this one LED for three status indicators or pulse width modulate all three and get mixed colors! Note: As of 1/2010, the pins in the datasheet are correctly labeled. Pin 3 is Green and Pin 4 is Blue. Those purchased prior to then will have Blue on Pin 3 and Green on Pin 4. Features: Forward Voltage (RGB): (2.0, 3.2,...

Texas Instruments CD74HC4067 16-Channel multiplexer. What can you do with it? How about taking an analog to digital reading from 16 devices with only 1 ADC channel and 4 control pins. That's right,...

Texas Instruments CD74HC4067 16-Channel multiplexer. What can you do with it? How about taking an analog to digital reading from 16 devices with only 1 ADC channel and 4 control pins. That's right, 16 for the price of 5! 24-Pin SSOP package. Works great with our 28-Pin SSOP to DIP adapters. Documents: Datasheet bildr blog - CD74HC4067 ...

Faster, cheaper, smaller, better, right? The SN754410 Quad Half H-Bridge is just that. Capable of driving high voltage motors using TTL 5V logic levels, the SN754410 can drive 4.5V up to 36V at 1A...

Faster, cheaper, smaller, better, right? The SN754410 Quad Half H-Bridge is just that. Capable of driving high voltage motors using TTL 5V logic levels, the SN754410 can drive 4.5V up to 36V at 1A continuous output current! Please see datasheet for more information. This is a pin to pin compatible replacement for the L293D. **Datasheets: **SN754410

"DC to DC converter/regulator MC34063A. Has an input range of 3V to 40V, output switch current of up to 1.5 amp. Step up, step down and invert capability. This is the unit we used in the high...

"DC to DC converter/regulator MC34063A. Has an input range of 3V to 40V, output switch current of up to 1.5 amp. Step up, step down and invert capability. This is the unit we used in the high voltage ringer circuit for the port-o-rotary phone! Documents:MC34063 Datasheet"

These are very common, high quality BJT NPN transistors made by ST Micro. Datasheet: 2N3904

These are very common, high quality BJT NPN transistors made by ST Micro. Datasheet: 2N3904

These are very common, high quality BJT, PNP transistors made by ST Micro. **Datasheet: **2N3906

These are very common, high quality BJT, PNP transistors made by ST Micro. **Datasheet: **2N3906

Low-profile electrolytic decoupling capacitors 10uF/25V. These capacitors are great transient/surge suppressors and work well as charge pump caps for MAX232 circuits. High quality radial...

Low-profile electrolytic decoupling capacitors 10uF/25V. These capacitors are great transient/surge suppressors and work well as charge pump caps for MAX232 circuits. High quality radial electrolytic capacitors. Check out our Unregulated Power Supply Tutorial

This is the basic LD1117V33 voltage regulator, a low drop positive regulator with a 3.3V fixed output voltage. This fixed regulator provides a great amount of stability and protection for your...

This is the basic LD1117V33 voltage regulator, a low drop positive regulator with a 3.3V fixed output voltage. This fixed regulator provides a great amount of stability and protection for your project and with its on chip trimming this regulator is able to reach an output voltage tolerance within ±1%. Each one of these voltage regulators can output a max current of 800mA. Features: Output Voltage: 3.3V Output Current: 800mA Dropout Voltage: 1V Internal Current and Thermal Limit Documents:...

This is the LM317TG voltage regulator, a three-terminal positive regulator with a 1.2V to 37V adjustable output voltage. This adjustable regulator provides a local regulation, internal current...

This is the LM317TG voltage regulator, a three-terminal positive regulator with a 1.2V to 37V adjustable output voltage. This adjustable regulator provides a local regulation, internal current limiting, thermal shut-down control, and safe area protection for your project. Did we mention that this guy is easy to use? It only requires two external resistors to set the output voltage. Each one of these voltage regulators can output a max current of 1.5A. Features: Output Voltage: 1.2V - 37V...

These are very bright LEDs. The LEDs are so bright that it hurts to look directly at them. Please take a look at the pictures to get an idea of the intensity. All lenses are clear. Features:...

These are very bright LEDs. The LEDs are so bright that it hurts to look directly at them. Please take a look at the pictures to get an idea of the intensity. All lenses are clear. Features: 9,000mcd brightness Standard size - T1 3/4 5mm 2.4V forward drop Max current 20mA Documents: Datasheet LED Tutorial ...

These are very bright LEDs. The LEDs are so bright that it hurts to look directly at them. Please take a look at the pictures to get an idea of the intensity. All lenses are clear. Features:...

These are very bright LEDs. The LEDs are so bright that it hurts to look directly at them. Please take a look at the pictures to get an idea of the intensity. All lenses are clear. Features: Standard Size - T1 3/4 5mm 10,000mcd brightness 2.4V forward drop Max current 20mA Documents: Datasheet LED Tutorial ...

These are very bright LEDs. The LEDs are so bright that it hurts to look directly at them. Please take a look at the pictures to get an idea of the intensity. All lenses are clear. Features:...

These are very bright LEDs. The LEDs are so bright that it hurts to look directly at them. Please take a look at the pictures to get an idea of the intensity. All lenses are clear. Features: Standard Size - T1 3/4 5mm Forward Voltage: Min: 3.2V Max: 3.4V Max current 20mA Documents: Datasheet LED Tutorial ...

LEDs - those blinky things. A must have for power indication, pin status, opto-electronic sensors, and fun blinky displays. This is a very standard red LED. The lens is 3mm in diameter, and is...

LEDs - those blinky things. A must have for power indication, pin status, opto-electronic sensors, and fun blinky displays. This is a very standard red LED. The lens is 3mm in diameter, and is diffused. Features: 1.8-2.2VDC forward drop Max current: 20mA Suggested using current: 16-18mA Luminous Intensity: 150-200mcd Documents: Datasheet LED Tutorial ...

Standard frequency crystals - use these crystals to provide a clock input to your microprocessor. Rated at 20pF capacitance and +/- 50ppm stability. Low profile HC49/US Package.

Standard frequency crystals - use these crystals to provide a clock input to your microprocessor. Rated at 20pF capacitance and +/- 50ppm stability. Low profile HC49/US Package.

Standard 'Watch' or Real-Time-Clock crystal. 32.768kHz means it is precisely half of a 16-bit counter. Start counting at 0x8000 (or 32768). When the counter rolls over from 65535 to 0, then you know...

Standard 'Watch' or Real-Time-Clock crystal. 32.768kHz means it is precisely half of a 16-bit counter. Start counting at 0x8000 (or 32768). When the counter rolls over from 65535 to 0, then you know that exactly one second has passed. Reset the interrupt, reset the counter, and start counting again! Rated at 12.5pF load capacitance, 35K ohm max (18K ohm typical) series resistance, and +/- 20ppm stability. Small cylinder package.

Resonators function like crystals but stick closer to their specified frequency over a full temperature range. These resonators are +/-0.5% or better from -20C-+80C. These resonators have built-in...

Resonators function like crystals but stick closer to their specified frequency over a full temperature range. These resonators are +/-0.5% or better from -20C-+80C. These resonators have built-in load capacitors so no external caps are needed. **Datasheets: ** 20MHz, 10/8/4MHz

The 'must have' IC for 3V projects. This is the RS232 converter IC that is capable of running at 3V and communicating with 3V logic. Comes in an easy to solder 16-Pin SOIC SMD package. Requires four...

The 'must have' IC for 3V projects. This is the RS232 converter IC that is capable of running at 3V and communicating with 3V logic. Comes in an easy to solder 16-Pin SOIC SMD package. Requires four external 0.1uF ceramic capacitors - no more 10uF monsters! Operates from 2.7V to 6V. Documents: [Datasheet ](http://cdn.sparkfun.com/datasheets/Components/General IC/SP3232EBCA-L.pdf)(3232EB)

This is a 1A Adjustable SOT-223 voltage regulator capable of outputting 1.2V to 18V. The LM1117 uses the same pin-out and setup as the popular LM317 adjustable regulator, contained in a handy...

This is a 1A Adjustable SOT-223 voltage regulator capable of outputting 1.2V to 18V. The LM1117 uses the same pin-out and setup as the popular LM317 adjustable regulator, contained in a handy surface mount package. Requires two external resistors to function. Documents: FAN1117A.pdf SFE Eagle Library has this part! Check out our Unregulated Power Supply Tutorial ...

Surface mount DPDT switch for those tight portable designs. Capable of switching up to 1.2VA (360mA at 3.3V and 240mA at 5V). Documents: Datasheet ...

Surface mount DPDT switch for those tight portable designs. Capable of switching up to 1.2VA (360mA at 3.3V and 240mA at 5V). Documents: Datasheet

"LED Matrix with dual-color LEDs. This small matrix has both bright-red and bright-green LEDs built into one common cathode housing. Unit comes with a black finish and a opaque LED lenses. The...

"LED Matrix with dual-color LEDs. This small matrix has both bright-red and bright-green LEDs built into one common cathode housing. Unit comes with a black finish and a opaque LED lenses. The picture does not quite do the matrix justice. The Red and Green LEDs are quite clear, and turning both on creates a nice yellow color. Dimensions: 0.275x1.25x1.25" Documents: Datasheet " ...

Nordic Semiconductor nRF24L01+. Transceiver chip operating in the 2.4GHz band. Take all the coolness of the nRF2401A and add some extra pipelines, buffers, and an auto-retransmit feature - very...

Nordic Semiconductor nRF24L01+. Transceiver chip operating in the 2.4GHz band. Take all the coolness of the nRF2401A and add some extra pipelines, buffers, and an auto-retransmit feature - very nice! The improved '+' version of the nRF24L01 includes more features and better range! Features: Drop in compatible with nRF24L01 1.9V-3.6V supply 2Mbit data rate New long range 250kbit option Auto acknowledge Auto re-transmit Multiceiver - 6 data pipes 32 byte separate TX and RX FIFOs 5V tolerant...

Yes you read that correctly - 10Farad capacitor. This small cap can be charged up and then slowly dissipated running an entire system for hours. Combine two in series for 5F/5V. Do not over voltage...

Yes you read that correctly - 10Farad capacitor. This small cap can be charged up and then slowly dissipated running an entire system for hours. Combine two in series for 5F/5V. Do not over voltage or reverse polarize these capacitors. Features: 13mm x 33.5mm Documents: Datasheet

This is a translucent silicon rubber button pad with 16 buttons originally inspired by the folks at monome.org. Each button has a hole underneath that accepts either a 3mm or 5mm standard LED. The...

This is a translucent silicon rubber button pad with 16 buttons originally inspired by the folks at monome.org. Each button has a hole underneath that accepts either a 3mm or 5mm standard LED. The idea is that you can create a button interface of your choice with the ability to display simple colors under each button. Mainly, we wanted to use our tri-color LEDs to create a full RGB color for each button. 16 button pad can be split up into four, 4 button pads. Each button has a conductive...

This is a translucent silicon rubber button pad with 4 buttons orignally inspired by the folks at monome.org. Each button has a hole underneath that accepts either a 3mm or 5mm standard LED. The...

This is a translucent silicon rubber button pad with 4 buttons orignally inspired by the folks at monome.org. Each button has a hole underneath that accepts either a 3mm or 5mm standard LED. The idea is that you can create a button interface of your choice with the ability to display simple colors under each button. Mainly, we wanted to use our tri-color LEDs to create a full RGB color for each button. Each button has a conductive circle backing so that a switch can be created with exposed PCB...

This is the very popular RGB combo but in SMD form. These units have four pads with a common anode configuration. Use this one LED for three status indicators or pulse width modulate all three and...

This is the very popular RGB combo but in SMD form. These units have four pads with a common anode configuration. Use this one LED for three status indicators or pulse width modulate all three and get mixed colors! Simple breakout board available below. Iv (Typical): Red: 81mcd Green: 130mcd Blue: 54mcd Vf (Typical): Red: 2.0V Green: 3.5V Blue: 3.5V Wavelength (λD - nm): Red: 615nm Green: 530nm Blue: 470nm Documents: Datasheet LED Tutorial ...

This is a small 12mm round speaker that operates around the audible 2kHz range. You can use these speakers to create simple music or user interfaces. This is not a true piezoelectric speaker but...

This is a small 12mm round speaker that operates around the audible 2kHz range. You can use these speakers to create simple music or user interfaces. This is not a true piezoelectric speaker but behaves similarly. Instead of a piezoelectric crystal that vibrates with an electric current, this tiny speaker uses an electromagnet to drive a thin metal sheet. That means you need to use some form of alternating current to get sound. The good news is that this speaker is tuned to respond best with a...

This a simple breakout board for the button pads. Each LED and button is brought out to the side connectors. The connectors are soldered to the back side of the PCB. We recommend trimming the...

This a simple breakout board for the button pads. Each LED and button is brought out to the side connectors. The connectors are soldered to the back side of the PCB. We recommend trimming the connector leads on the button side as short as possible to reduce the deflection of the pad. Now with footprints for diodes! Use the super cheap 1N4148 through-hole diodes. These can be used to isolate the switches to make for a bit easier decoding. Documents: Schematic Eagle Files Hookup Guide Datasheet...

DIP switch with 8 individual switch positions. The pins have .1" spacing - fits great into a breadboard! Works great as general control switches. Documents: Datasheet ...

DIP switch with 8 individual switch positions. The pins have .1" spacing - fits great into a breadboard! Works great as general control switches. Documents: Datasheet

This is a small ambient light sensor that acts as an NPN transistor. The more the sensor is exposed to light, the stronger the base bias. Simple to use! Simple breakout board available below....

This is a small ambient light sensor that acts as an NPN transistor. The more the sensor is exposed to light, the stronger the base bias. Simple to use! Simple breakout board available below. Documents: Hookup Guide Datasheet

This is a handy little device that can save your system from smoking. A resettable fuse (also known as a PTC) is a resistor that has very unique properties. For this model, if your circuit tries to...

This is a handy little device that can save your system from smoking. A resettable fuse (also known as a PTC) is a resistor that has very unique properties. For this model, if your circuit tries to draw more than 250mA of current (if you have a bad short for instance) the PTC would 'trip' (by heating up). The increased resistance (trip state) would break the circuit and allow only a small leakage current. The leakage current may still be enough to hurt some electronics but it's much less than...

1/6th Watt, +/- 5% tolerance PTH resistors. Commonly used in breadboards and perf boards, these 330Ohm resistors make excellent LED current limiters and are great for general use. Need more than...

1/6th Watt, +/- 5% tolerance PTH resistors. Commonly used in breadboards and perf boards, these 330Ohm resistors make excellent LED current limiters and are great for general use. Need more than one? Checkout our bags of resistors. Documents: Breadboard Lecture Sold in single pieces

Your basic 7-segment LED. Common anode. Two decimal points, but only the one on the right is wired. Digit height is 0.6". Overall height is 1" Documents: Datasheet Arduino Library (Thanks Derek!) ...

Your basic 7-segment LED. Common anode. Two decimal points, but only the one on the right is wired. Digit height is 0.6". Overall height is 1" Documents: Datasheet Arduino Library (Thanks Derek!)

This is a very common 22pF capacitor. Used with crystals for loading purposes. 0.1" spaced leads make this a perfect candidate for breadboarding and perf boarding. Rated at 200V. Sold in single...

This is a very common 22pF capacitor. Used with crystals for loading purposes. 0.1" spaced leads make this a perfect candidate for breadboarding and perf boarding. Rated at 200V. Sold in single pieces Documents: Crystal Oscillator Lecture

BlinkM is a “Smart LED”, a networkable and programmable full-color RGB LED for hobbyists, industrial designers, prototypers, and experimenters. It is designed to allow the easy addition of dynamic...

BlinkM is a “Smart LED”, a networkable and programmable full-color RGB LED for hobbyists, industrial designers, prototypers, and experimenters. It is designed to allow the easy addition of dynamic indicators, displays, and lighting to existing or new projects. If you’ve used up all your microcontroller PWM channels controlling RGB LEDs and still want more, BlinkM is for you. BlinkM uses a high quality, high power RGB LED and a small AVR microcontroller to allow a user to digitally control an...

This is a very common signal diode - 1N4148. Use this for signals up to 200mA of current. Documents: Datasheet ...

This is a very common signal diode - 1N4148. Use this for signals up to 200mA of current. Documents: Datasheet

This is a simple, subminiature size, axial lead mounted rectifier diode. Often used for reverse voltage protection, the 1N4001 is a staple for many power, DC to DC step up, and breadboard projects....

This is a simple, subminiature size, axial lead mounted rectifier diode. Often used for reverse voltage protection, the 1N4001 is a staple for many power, DC to DC step up, and breadboard projects. The 1N4001 is rated for up to 1A/50V. Documents: Datasheet

Small electret microphone. Useful in acoustic and audio applications. Documents: Datasheet Example Audio LED control project by Adam Greig ...

Small electret microphone. Useful in acoustic and audio applications. Documents: Datasheet Example Audio LED control project by Adam Greig

The MCP3002 has a 10-bit analog to digital converter (ADC) with a simple to use SPI interface. Use this IC if your microcontroller does not have an ADC or have enough ADC lines. A great chip when...

The MCP3002 has a 10-bit analog to digital converter (ADC) with a simple to use SPI interface. Use this IC if your microcontroller does not have an ADC or have enough ADC lines. A great chip when you need to add additional ADC lines. Features: 2.7V to 5.5V supply 10-bit resolution 8-pin DIP package 3 wire SPI interface Up to 75,000 samples per second Low power shutdown Documents: Datasheet ...

This is a small device called a reed switch. When the device is exposed to a magnetic field, the two ferrous materials inside the switch pull together and the switch closes. When the magnetic field...

This is a small device called a reed switch. When the device is exposed to a magnetic field, the two ferrous materials inside the switch pull together and the switch closes. When the magnetic field is removed, the reeds separate and the switch opens. This makes for a great non-contact switch. This switch can carry up to 1.2A. Documents: Datasheet Hookup Guide Application Note Videos ...

These are small rare earth magnets - 0.25" cubed. Composed of Neodymium/Iron/Boron (NdFeB), these magnets are curiously strong and make for a great way to attach tools to a metal workbench, hold...

These are small rare earth magnets - 0.25" cubed. Composed of Neodymium/Iron/Boron (NdFeB), these magnets are curiously strong and make for a great way to attach tools to a metal workbench, hold small children to a fridge, and as a trigger for reed switches. Activates the reed switch (shown below) at a distance of about 3cm. Sold in single units.

These are very small rare earth magnets - 0.125" cubed. Composed of Neodymium/Iron/Boron (NdFeB), these magnets are curiously strong and make for a great way to attach tools to a metal workbench,...

These are very small rare earth magnets - 0.125" cubed. Composed of Neodymium/Iron/Boron (NdFeB), these magnets are curiously strong and make for a great way to attach tools to a metal workbench, hold small children to a fridge, and as a trigger for reed switches. Don't let the photo fool you - these are very small magnets. Activates the reed switch (shown below) at a distance of about 1cm. Sold in single units.

This is a simple 5mm LED with an interesting array of applications. This UV LED can be used for counterfeit detection (bills, credit cards, documents, etc), sterilization, pesticide, black lights,...

This is a simple 5mm LED with an interesting array of applications. This UV LED can be used for counterfeit detection (bills, credit cards, documents, etc), sterilization, pesticide, black lights, sun burns, the list goes on. Please wear eye protection when using these LEDs. Features: T1 3/4 5mm clear lens 395-400nm 100-180mcd 3-3.6V forward drop Documents: Datasheet LED Tutorial All About LEDs ...

Miniature surface mount momentary button. These are great, low-profile momentary switches. Perfect as a tactile reset switch. Rated up to 50mA. Documents: Dimensional Drawing ...

Miniature surface mount momentary button. These are great, low-profile momentary switches. Perfect as a tactile reset switch. Rated up to 50mA. Documents: Dimensional Drawing

This is a black plastic bezel, custom made to mate with the silicon rubber pads. Black 1/8" ABS plastic. We use four 4/40-0.5" size screws matched with plastic standoffs to attach the 2x2 button pad...

This is a black plastic bezel, custom made to mate with the silicon rubber pads. Black 1/8" ABS plastic. We use four 4/40-0.5" size screws matched with plastic standoffs to attach the 2x2 button pad and Simon project boards. Using two of these bezels with two of the bottom bezels will create a 4x4 bezel appropriate for the full button pad. Documents: Dimensional Multi-Unit Assembly 3D Model ...

This is a black plastic bezel, custom made to mate with the silicon rubber pads. Black 1/8" ABS plastic. Using two of these bezels with two of the top bezels will create a 4x4 bezel appropriate for...

This is a black plastic bezel, custom made to mate with the silicon rubber pads. Black 1/8" ABS plastic. Using two of these bezels with two of the top bezels will create a 4x4 bezel appropriate for the full button pad. Documents: Dimensional Multi-Unit Assembly 3D Model ...

Your project will probably need an on/off switch. If you plan to house the project in an enclosure, we found this great rocker switch to help you out. RoHS and UL approved. Features: Right angle...

Your project will probably need an on/off switch. If you plan to house the project in an enclosure, we found this great rocker switch to help you out. RoHS and UL approved. Features: Right angle solid through-hole mounting Can also be snap-in panel mounted Rated up to 15A @ 125V Documents: Mechanical Drawing ...
